Description:
425 FMT PBT PO-D

Pneumatic Piston-Balanced Throttling Liquid Dump Valves use equal percentage trim for throttling control. The orientation of the trim is better for erosive service because the trim moves up out of the flow path.

Designed for liquid systems, and available in either pressure-opening (normally closed) or pressure-closing (normally open) configurations.

Build & Save a Quote

We'll get you options, pricing, and anything else you need.

Helpful Face

Anything we can do to help?

Talk to a specialist at (405) 525-4298 or fill out a quick product message form.

Need Service?

Our certified technicians work closely with our engineering and product design teams.

They have direct access to the most up-to-date product information.

Request Service

Repairs & Maintenance

Browse our Accessories and our Repair Kits to keep your Kimray product in peak condition.

We recently consolidated our regulator repair kits. Please see the related product notice for a full cross-reference table.

Product Applications

Applications Image
Zoom in on interactive diagrams.

Product Charts

1 of 1: Flow Coefficient (Cv) at Stem Travel (% Open)
10%
11.7
20%
18.1
30%
24.8
40%
36.8
50%
58.3
60%
86.1
70%
114
80%
137
90%
152.8
100%
160

Tech Specs

Type Value
Connection Size: 4 "
Connection Type: 150 RF
Body Style: Through Body
Body Material: Cast Ductile
NACE MR0175: Option Available
Trim Size: 4 "
Trim Type: Equal Percentage
Leakage Class: Class VI
Process Fluid: Liquid and Gas
Max Working Pressure: 250 psig
Actuator Spring Nominal Pressure: 35 psig
Actuator Crack Open Pressure: 10 psig
Actuator Full Open Pressure: 35 psig
Max Supply Gas Pressure: 45 psig
Fail Position: Closed
Operation: Pneumatic
Face-to-Face Length: 15 "
Min Cv: 18.1
Max Cv: 160
Cf: 0.75
